Digital universal caliper 0 - 150 mm range 3V
€210.00
Available, delivery time: 1-3 workdays
Product information "Digital universal caliper 0 - 150 mm range 3V"
Digital universal caliper 0 - 150 mm with exchangeable tips
- for inside and outside measuring
- made of stainless steel, hardened
- with 5 mm hole for measuring tips 5 mm shank
- with 7 pairs of measuring tips
- measuring system with 3 V
- metal casing
- with ON/OFF and ZERO/PRESET button
- data output (RB 5)
- reading 0,01 mm
- accuracy 0,04 mm
- Length jaws: 45 mm
- in case/box
Range 0 - 150 mm
| Accuracy: | 0,04 mm |
|---|---|
| Data output: | RB 5 |
| Range: | 0 - 150 mm |
| Reading: | 0,01 mm |
| Type: | digital, Measuring system with 3 V, with metal casing |
Technical Data
| Messbereich mm Range mm |
Genauigkeit mm Accuracy mm |
L mm |
| 0 - 150 | 0,04 | 45 |
Product Safety Information:
- Suitable only for technically skilled users familiar with the product and for craftsmen.
- Intended solely for the designated purpose.
- Improper use may lead to damage and injuries.
Importer/Manufacturer:
Gedema GmbH
Berchumer Str. 74
58093 Hagen
Email: info@messwelt.com
Email: info@gedema.com
Items explicitly stating the manufacturer are excluded.
Accessories
Certification for caliper until 200 mm - for analog and digital caliper until range 200 mm - the calibration will be done by an external calibration laboratory - certification rule VDI/VDE/DGQ 2618 or manufacture standard
Connection cable for devices with RB 5 data output - length about 100 cm- connection cable RB 5 / RB 5 for connecting the measuring device to the USB interface no. 220.250.2
Extension length 50 mm for measuring tips - extension for measuring tips Ø 5 mm with thread M 2,5- length 50 mm
Extension length 100 mm for measuring tips - extension for measuring tips Ø 5 mm with thread M 2,5- length 100 mm
