Micrometer 150 - 300 mm with 6 exchangeable anvils
€198.00
Available, delivery time: 1-3 workdays
Product information "Micrometer 150 - 300 mm with 6 exchangeable anvils "
Micrometer 150 - 300 mm with exchangeable anvils
- with exchangeable anvils
- with carbide measuring faces
- spindle Ø 8,0 mm
- thimble chrome finished
- thread pitch 0,5 mm
- with ratchet and setting standard
- reading 0,01 mm
- accuracy manufacture standard
- accuracy 0,013 mm
- in case/box
Range 150 - 300 mm
| Accuracy: | 0,013 mm |
|---|---|
| Range: | 150 - 300 mm |
| Reading: | 0,01 mm |
| Type: | analogue, with carbide measuring faces, with exchangable anvils, with ratchet |
Technical Data
| Messbereich mm Range mm |
Genauigkeit mm Accuracy mm |
Amboss / Stk. Anvils / pcs. |
Einstellmaß mm Standard mm |
| 150 - 300 | 0,013 | 6 | 150/175/200/225/250/275 |
Product Safety Information:
- Suitable only for technically skilled users familiar with the product and for craftsmen.
- Intended solely for the designated purpose.
- Improper use may lead to damage and injuries.
Importer/Manufacturer:
Gedema GmbH
Berchumer Str. 74
58093 Hagen
Email: info@messwelt.com
Email: info@gedema.com
Items explicitly stating the manufacturer are excluded.
Accessories
Micrometer holder for mircrometer until 200 mm - for micrometer until 200 mm - with adjustable angle and central clamp - base Ø 100 mm - weight 1,5 kg
Certication for micrometer > 150 - 300 mm - for analog and digital micrometer with exchangeable anvil range > 150 - 300 mm - the calibration will be done by an external calibration laboratory - certification rule VDI/VDE/DGQ 2618 or manufacture standard
