Tube micrometer measuring from 1,8 mm 0 - 25 mm
€41.34
Available, delivery time: 1-3 workdays
Product information "Tube micrometer measuring from 1,8 mm 0 - 25 mm "
Tube micrometer 0 - 25 mm
- for measuring of wall thickness from 1,8 mm
- carbide face
- frame coated
- thimble chrome finished
- with ratchet, reading 0,01 mm
- accuracy 0,004 mm
- in case/box
Range 0 - 25 mm
| Accuracy: | 0,004 mm |
|---|---|
| Range: | 0 - 25 mm |
| Reading: | 0,01 mm |
| Type: | analogue, Tube micrometer, with ratchet |
Technical Data
| Messbereich mm Range mm |
Messung ab mm Measuring at mm |
Genauigkeit mm Accuracy mm |
| 0 - 25 | 1,8 | 0,004 |
Product Safety Information:
- Suitable only for technically skilled users familiar with the product and for craftsmen.
- Intended solely for the designated purpose.
- Improper use may lead to damage and injuries.
Importer/Manufacturer:
Gedema GmbH
Berchumer Str. 74
58093 Hagen
Email: info@messwelt.com
Email: info@gedema.com
Items explicitly stating the manufacturer are excluded.
Accessories
Micrometer holder for micrometer until 300 mm - for micrometer until 300 mm - with adjustable angle and central clamp - heavy type - weight 2 kg
Certification tube micrometer - for analog and digital tube micrometer until range 25 mm - the calibration will be done by an external calibration laboratory - certification rule VDI/VDE/DGQ 2618 or manufacture standard
