Digital micrometer 75 - 100 mm IP 65 DIN 863

Product information "Digital micrometer 75 - 100 mm IP 65 DIN 863"

Digital micrometer 75 - 100 mm IP 65

- frame coated, thimble chrome finished
- carbide measuring faces Ø 6,5 mm
- with ratchet
- display with on/0, mm/inch, abs and hold button
- reading: 0,001 mm, accuracy DIN 863
- with data output RB 4
- with setting standard
- in case/box

Range 75 - 100 mm

Accuracy: DIN 863
Data output: RB 4
Protection class: IP 65
Range: 75 - 100 mm
Reading: 0,001 mm
Type: digital, with carbide measuring faces, with ratchet

Technical Data

Messbereich mm
Range mm
Schutzklasse
Protection
a mm L mm
75 - 100 IP 65 61 108
